Holzfforma G660 MS660 066 Power Head Chainsaw 92CC Full Wrap Handle Bar Wagners

his is a TOP QUALITY 92CC Holzfforma Brand Gasoline Chain Saw Without Guide Bar and Chain, produced by Farmertec Machinery.


It is with full wrap handle bar ,Magnesium Alloy Recoil Starter/Crankcase/Sprocket Cover as shown in the picture, make your work easier and safer.


Technical Specifications:

Chainsaw type Holzfforma single cylinder 2 stroke engine

Total Mass Without bar and chain 8kgs

Cylinder Displacement 91.6cm3 (5.6 cu.in.)

Power Output to ISO 7293 7.0HP(5.2KW)

Idle Speed 2,500 RPM

Maximum Power Speed 13,500 RPM

Cylinder Bore 54 MM (2.13 IN)

Cylinder Stroke 40 MM (1.57 IN)


Fuel System

Carburetor Model Name Diaphragm carburetor

Air Filter HD Type

Fuel Type Unleaded 90+RON

Fuel Mix 2 stroke 25:1 (25 parts of unleaded fuel to 1 part of 2 stroke oil)

Fuel Tank Volume 27.9 fl.oz (0.825 l)


Cutting Attachments

Guide Bar 20", 25", 28", 32" or 36"

Maximum Cutting Length 50 ,63, 70, 80 or 90 cm

Guide Bar Type Sprocket nose

Chain Type 3/8" , .063"

Chain Sprocket Standard 7 tooth 3/8" pitch

Chain Lubrication Fully automatic oil pump

Bar Oil Type SAE#10W-30 or Similar

Oil Tank Capacity 12.2 fl.oz (0.36 l)


INCLUDE

1PC Chainsaw Power Head 92CC

1PC Fuel Oil Mixing Bottle

1PC User Manual

1PC Fuel Tank Protect Cover

1SET Tool






Warranty
For Home Users：6 Months
For Commercial Users：3 Months
